KPMI® Shim In Tappet Valve Spring Kits and White Diamond® Valves for Various Applications
KPMI® shim in tappet systems locate the adjustment shim in the hardened steel of the tappet body, where it is impervious to wearing (ovalling) and kicking the shim out. By designing the tappet and Titanium or H.T. Steel retainer together as a system, the shim counterbore depth in the tappet has been maximized. This allows for increased insurance against losing the shim even in the event of valvetrain separation during severe operating conditions, over-revs, or extreme boost pressures.
Inconel® is classified as a “Super Alloy”, meaning that it is designed to survive under the most extreme temperatures and pressures where other valves will begin to burn, corrode, or completely fail. This is the material of choice for high output engines running turbos, superchargers, nitromethane, or nitrous.
To learn more about these Kibblewhite® Shim in Tappet Valve Spring Kit and other valvetrain related components for the various models, go to
KPMI® Chrome Moly Tube Pushrods for Various Norton® and Triumph® Applications
• KPMI® Pushrods are designed with thin wall Chrome Moly Tube for increased stiffness over OEM components
• Male and female endpieces are made from hardened steel and offer increased wear resistance over aluminum OEM parts
• Designed for Norton® and Triumph® applications but can be used as desired (see dimensions for fitment)
• See www.kpmi.us for our full lineup of pushrods
To learn more about these Kibblewhite® Chrome Moly Tube Pushrods and other valvetrain related components for the various models, go to
KPMI® H.T. Steel Cylinder Kits for Various Honda® and Yamaha® Applications
• Nuts are machined from billet high tensile steel and heat treated
• Studs are heat treated 180,000 PSI aircraft alloy steel
• Both nut and stud have rolled threads for the strongest possible threads
• Both nut and stud are black oxide treated for enhanced corrosion resistance
To learn more about these Kibblewhite® H.T. Steel Cylinder Stud Kits and other valvetrain related components for the various models, go to
Honda® XR™ 400R RFVC 1996-2004
Honda® TRX™ 400EX 1999-2014/ TRX™ 400X 2009-2014
Yamaha® Various 700's 2006-2021
Yamaha® Various 660's 2001-2008
Tech Bulletin- Superseded Kawasaki® and Suzuki® GSX-R 1000 Valves
KPMI® has Suzuki® valve designs whereas we have selected a proprietary material and heat treatment process that enhances the durability of the valve face to retard valve face recession. For several years now, this material and heat treatment process was coupled with the KPMI® Black Diamond™ surface treatment. During the heat treatment stage of manufacturing, the Black Diamond™ coating would come under attack and suffer oxidation and corrosion, leaving a new valve looking used. Although this combination of processes did achieve a superior stainless one piece valve that would prove to have a highly durable valve face, the valve heads had an unaesthetic appearance (see Figure 1 and 2). Recently, the KPMI® engineering department completed design reviews for all valves with these issues. The solution was to move away from the KPMI® Black Diamond™ treatment and introduce the well-recognized and proven KPMI® White Diamond® coating and then post process after heat treatment to leave the head of the valve in a beautiful polished stainless finish (see Figure 1 and 2). We hope you are as excited as we are to provide you with these enhanced valve designs that we will be introducing in a superseding fashion over the next few months.
Please refer to 5th round of the updated superseded part numbers, go to
Figure 1
KPMI® H.T. Steel Cylinder Kit for Suzuki® GSX-1300R™ Hayabusa™ 1999-2019
• Heat treated 180,000 PSI aircraft alloy steel
• Centerless ground to remove material imperfections
• Rolled threads for the strongest threads period
• Black oxide treated for enhanced corrosion resistance
• 5mm Allen Hex to ease installation and removal
To learn more about these Kibblewhite® H.T. Steel Cylinder Stud Kit and other valvetrain related components, go to
Suzuki® GSX-1300R™ Hayabusa™ 1999-2019
Valves, O.E.M. Repl., Tensilite® Titanium for Honda® CRF250R / RX 2018-2021
• Dimensionally identical to O.E.M. valves while offering many advantages
• One piece forged Titanium alloy offers uninterrupted grain flow
• Superior tensile strength and stability at and above operating temperatures
• Every surface either fully CNC machined or precision ground
• Super-finished stem allowing for Formula 1 level coating consistency
• 100% Chromium Nitride (CrN) PVD coated
• Material and workmanship that provide outstanding durability and performance
• Competitive pricing allowing for a value conscious rebuild
To learn more about other Kibblewhite® Husqvarna® and KTM® parts and accessories, go to
Honda® CRF250R/ RX 2018-2021
KPMI® Various Valve Spring Kits for Polaris® XP900/ 1000's Applications
KPMI® has developed a Beehive Spring Kit and 3 Dual-Spring Kits for the 2011-’16 Polaris XP900/1000’s and 2 Dual-Spring Kits and a Beehive Kit for the 2013- ’20 900/1000’s. Being at the forefront of valvetrain development in the side by side market, KPMI® takes pride in being able to development spring kits for the top engine builders around the world. Because of this fact, KPMI® processes valued feedback when offering new designs or modifying existing. Pay close attention to the pressures and retainer material offered. KPMI® recommends heat-treated-steel-retainers for all endurance applications and leaves it up to the most experience engine builder to select titanium retainers when mass reduction is imperative and normal maintenance teardowns are routine after each race. As an additional note, our race customers are using less open pressure for the Turbo’s and only using the Beehive and higher open pressure with experience and knowledge of the treatment of mating parts, clearances and oils. Matching a spring design to given valvetrain mass and cam dynamics is a science and when in doubt you must confer with an experienced builder.
To learn more about these Kibblewhite® Valve Spring Kits and other valvetrain related components for the various models, go to
Polaris® RZR™ XP 900 2011-2012
Polaris® RZR™ XP 900 2013-2014
KPMI® Lightweight Racing Dual Spring Kits for Various Harley-Davidson® Applications
• Lightweight Racing Dual Spring Kits for 0.650” and 0.675” lift
• For the 7mm valve stem applications listed
• Retainers designed for optimum rocker cover clearance
• Includes Heavy Duty 9° H.T. Steel Keepers and Red Viton® Seals
To learn more about these Kibblewhite® Lightweight Racing Dual Spring Kits and other valvetrain related components for the various models, go to
Harley-Davidson® Evo Sportster™ 833cc 2004-2021
Harley-Davidson® Evo Sportster™ 1200cc 2004-2021
2nd Round Top End Service Kits - Stainless Conversion for Various Honda® and Suzuki® Applications
ALL KIT CONTENTS
• High Compression Racing Piston with Coated Skirt (with rings and pin)
• Top End Gasket Kit (Head Gasket, Base Gasket, Exhaust Gasket, Cam Chain Tensioner Gasket, Valve Stem Seals, Cylinder Head Drain Seal)
• Std. Black Diamond™ or White Diamond® Stainless Valves
• Lightweight Racing Spring Kit (Titanium Retainers, Dual Springs, H.T. Steel Basewashers)
FEATURES
• Designed specifically for the performance demands of popular racing MX Bikes and Quads.
• Pistons designed to maintain the stock compression after the effects of the dished stainless valves
• 2618 Alloy Fully CNC Machined Piston with performance skirt coating
• Black Diamond™ and White Diamond® Stainless Steel Conversion system significantly increases valve durability
• Lightweight Racing Spring Kit Compatible with high performance cams
• All of the gaskets, rings, pins and seals required for a top end rebuild
IMPORTANT NOTE: The piston, rings, valves and pin clips in this kit are designed to work together as a system. They are NOT COMPATIBLE with O.E.M. components and should ONLY be used with the components in this KPMI® Top End Service Kit.
To learn more about other Kibblewhite® Various Honda® and Suzuki® parts and accessories, go to
Honda® CRF 250R 2004-2007 / 250X 2004-2017
Suzuki® LT-Z 400 2003-2018
Figure 2
KPMI® H.T. Steel Cylinder Kits for Various Honda® Applications
• Nuts are machined from billet high tensile steel and heat treated
• Studs are heat treated 180,000 PSI aircraft alloy steel
• Both nut and stud have rolled threads for the strongest possible threads
• Both nut and stud are black oxide treated for enhanced corrosion resistance
To learn more about these Kibblewhite® H.T. Steel Cylinder Stud Kits and other valvetrain related components for the various models, go to
Guides, +0.025", Mag. Brz, Av&V Style for Various Harley-Davidson® Applications
These Engine Builder valve guides have been designed with the price conscious builder in mind. Expect the same exacting KPMI® tolerances, but with a reduced toughness / wear-ability when compared to premium C630 Nickel Aluminum Bronze valve guides. The softer Manganese guides are easily reamed, and then can be delicately finished with our high quality ball hones. Now, with any battery operated or electric drill you can ream and hone manganese valve guides in less time and in the absence of expensive honing equipment required to properly size tough Nickel Bronze guides.
To learn more about these Kibblewhite® Valve Guides and other valvetrain related components, go to
Harley-Davidson® Evolution™ 1984-1999
Harley-Davidson® Twin Cam™ 88" 1999-2004
Harley-Davidson® XL™ 1100cc 1986-1987
Lightweight Racing Spring Kit and Components for Honda® Various 250- 300's 2011-2020
Since 1939, KPMI® has taken great pride in our ability to design innovative performance improvements for valvetrains. This innovative ability has never been more apparent than with the development of the high tech lightweight racing valve spring kits for the incredibly stressed and torturous environment in today’s high revving 4-stroke engines. The challenge to engineer a valvetrain that would outperform OEM systems, that in some cases included titanium components, was not an easy one. This task would require the concentrated efforts of every member of KPMI®’s design team. It was apparent early on that an OEM style spring with a bit more pressure was not going to be the complete answer for these engines. Working together as a team enabled KPMI® to evolve with a “unified system” approach. In fact, these innovative high performance lightweight valve spring kits, would not only outperform factory parts, but outlive them as well. Each KPMI® spring kit is designed for its specific application, taking into account several critical parameters including; cam profiles, harmonics, natural frequency of the springs, valvetrain mass, required pressure, wire stress, fatigue life, and engine rpm, just to name a few! Today KPMI® proudly offers complete high performance lightweight valve spring kits for a host of applications.
We choose to use the copper based C63000 nickel-aluminum bronze as a material to make our bronze valve guides because of its ideal characteristics for the application. The 5% nickel content provides superior resistance to wear, and the approximately 80 percent copper content delivers outstanding heat conductivity. KPMI® guide profiles are designed to have minimal effect on the airstream while maintaining critical cross sectional thickness in high temperature areas, which promotes high performance and endurance.
All KPMI® Black Diamond™ Stainless steel valves are impregnated by a special German process to a depth of .002, with a surface build up of .0002. This Black Diamond process improves wear properties, reduces friction, and provides resistance to corrosion and wear that is superior to chrome and nickel electrolysis plating. Each valve is designed using Finite Element Analysis software, and profiles are tested on our computerized flow bench. Black Diamond Valves are lightweight, strong, one piece forgings with profiles that provide excellent flow characteristics.
To learn more about these Kibblewhite® Lightweight Racing Spring Kits and other valvetrain related components, go to
Honda ® Various 250-300's 2011-2020
